Tool & Die:
|
8017
|
SMA, SMB, SFR, ST, SC Type
|
Universal for sleeves and ferrules,
|
|
Die Only:
|
2652
|
0.128″ / 0.151″ / 0.215″ / 0.197″ /
0.178″ HEX
|
SC, FC, SMA
|
|
|
|
(3.2 / 3.83 / 5.46 / 5.0 / 4.52 mm)
|
|
|
Tool & Die:
|
8018
|
SMA/FC Type
|
Crimps ferrules and sleeves only,
|
|
Die Only:
|
2043
|
0.215″ / 0.178″ / 0.151″ HEX
|
SMA, FC
|
|
|
|
(5.46 / 4.52 / 3.83 mm)
|
|
|
Tool & Die:
|
8019
|
SRF and SMF Type
|
Crimps ferrules and sleeves
|
|
Die Only:
|
2030
|
0.190″ / 0.160″ / 0.132″ RND
|
AMP (Tyco)
|
|
|
|
(4.83 / 4.06 / 3.35 mm)
|
|
|
Tool & Die:
|
8020
|
Lucent Technologies ST II Type
|
Crimps ferrules and sleeves
|
|
Die Only:
|
2654
|
0.190″ HEX / 0.105″ RND /
0.090″ RND
|
Lucent ST II
|
|
|
|
(4.83 / 2.67 / 2.3 mm)
|
|
|
Tool & Die:
|
8037
|
3M SC / FC-3
|
Connectors with round crimp
|
|
Die Only:
|
2669
|
0.120″ RND / 0.137″ RND /
0.190″ RND
|
3M SC / FC Type Fiber
|
|
|
|
(3.05 / 3.48 / 4.83 mm)
|
|
|
Tool Die:
|
8039
|
FC / SC / ST / LC / SMA / MT-RJ
|
Crimps 3M. SC / ST & Lucent / Krone LC,
|
|
Die Only:
|
2685
|
0.151″ / 0.178″ HEX; LC RND /
0.190″ RND
|
SMA, FC, MT-RJ
|
|
|
|
(3.83 / 4.52 / LC / 4.83 mm)
|
LC RND dimension proprietary
|
|
Tool & Die:
|
8050
|
AMP SC 2.0 / 2.5 / 3.0 mm
|
Connectors with round crimp
|
|
Die Only:
|
2695
|
.110 / .125 / .140 / .191 RND
|
AMP SC
|
