Features
1. Stable glue exudation without glue leaking and dripping
2. Many kinds needles/syringes, dispensing valve and controller, to meet different requirements
3. Could set glue size, glue speed, dispensing time, stopping glue time.
4. High performance and cost-effective linear structure platform
5. High precision stepper motor control, trajectory precision dispensing
Specifications
|
1. Machine Size
|
180*140*90(mm)
|
|
2. Heating Temperature
|
40-200℃
|
|
3. Accuracy
|
±5℃
|
|
4. Power Consumption
|
200W
|
|
5. Input Voltage
|
AC 110V or AC 220V
|
|
6. Normal Curing period
|
30-45min
|
|
7. Normal Curing temperature
|
80-120℃
|
|
8. Net Weight
|
2 kg
|
|
9. Capacity
|
24 connectors
|
|
10. Materials
|
Stainless steel
|
Applications
1. Universal curing oven fiber optic connector manufacturer
2. Using to heat and solidify each kind of connectors
3. Epoxy curing for FC,SC,LC,MU,ST connectors
4. Used in house or field operation or with toolkit
