Key Feature:
No need air pressure, motor driven, strong riveting
Powerful, 1500 ~ 2000kgf crimping
Automatic mode, foot switch operation
Manual mode, easy to adjust or install the die
Crimping stroke 0 ~ 30mm adjustable
External lighting is convenient for quality inspection after crimping
It has counting function to count the number of products processed
The speed of the press is adjustable
Specification:
|
Part Number
|
FCCM-4001
|
|
Pressure Source
|
Motor Drice/ Electric Motor
|
|
Pressure Value
|
1500~2000kgf
|
|
Standard Crimping Die Size (mm)
|
3/ 3.2/ 3.3/ 3.84/ 4.2/ 4.3/ 4.52mm (Customizable)
|
|
Crimping Type
|
Fiber Optic Connector Snap Ring, MPO Connector Snap Ring, Wire and Metal Terminals
|
|
Voltage
|
220V 50Hz
|
|
Power
|
600W
|
|
Efficiency
|
4000 times/hour
|
|
Dimensions
|
260*240*600mm
|
|
Package Size
|
360*340*700mm
|
|
Net Weight
|
37kg
|
|
Gross Weight
|
39kg
|
